R Series Economical Inline Helical Gear Speed Reducer Inline Transmission Device Helical Gearbox
reviews
Item specifics
- Warranty:
- 3 years
- Applicable Industries:
- Manufacturing Plant
- Weight (KG):
- 60 KG
- Customized support:
- OEM, ODM, OBM
- Gearing Arrangement:
- Helical
- Output Torque:
- 3.5Nm - 23200Nm
- Input Speed:
- 0.06-1.9r/min
- Output Speed:
- 0.06-1.9r/min
- Place of Origin:
- Zhejiang, China
- Brand Name:
- SL
- Ratio:
- 1:1
- Gear Type:
- Helical
- Output Shaft Type:
- output hub
- Mounting Orientation:
- Horizontal
- Maximum Input Horsepower:
- 1HP
- Product name:
- Helical Gearbox
Description
Products Description
Speed Reducer Suppliers China Manufacturer helical Motor Speed Reducer
Components:
1. Housing: Cast Iron
2. Gears: Helical Gears
3. Input Configurations:
Equipped with Electric Motors
Solid Shaft Input
IEC or NEMA Motor Flange
1. Housing: Cast Iron
2. Gears: Helical Gears
3. Input Configurations:
Equipped with Electric Motors
Solid Shaft Input
IEC or NEMA Motor Flange
4. Applicable Motors:
Single Phase AC Motor, Three Phase AC Motor
Brake Motors, Inverter Motors
Multi-speed Motors, Explosion-proof Motor
Roller Motor
5. Output Configurations: Solid Shaft Output
Single Phase AC Motor, Three Phase AC Motor
Brake Motors, Inverter Motors
Multi-speed Motors, Explosion-proof Motor
Roller Motor
5. Output Configurations: Solid Shaft Output
Models:
R Series (Foot-mounted): R18~R168
RS Series (Foot-mounted, Solid Shaft Input)
RF Series (Flange-mounted): RF18~RF168
RFS Series (Flange-mounted, Solid Shaft Input)
RX Series (1 Stage, Foot-mounted): RX38~RX158
RXS Series (1 Stage, Foot-mounted, Solid Shaft Input)
RXF Series (1 Stage, Flange-mounted): RXF38~RXF158
RXFS Series (1 Stage, Flange-mounted, Solid Shaft Input)
RM Series (agitator gearboxes): Specially designed for agitating applications
R Series (Foot-mounted): R18~R168
RS Series (Foot-mounted, Solid Shaft Input)
RF Series (Flange-mounted): RF18~RF168
RFS Series (Flange-mounted, Solid Shaft Input)
RX Series (1 Stage, Foot-mounted): RX38~RX158
RXS Series (1 Stage, Foot-mounted, Solid Shaft Input)
RXF Series (1 Stage, Flange-mounted): RXF38~RXF158
RXFS Series (1 Stage, Flange-mounted, Solid Shaft Input)
RM Series (agitator gearboxes): Specially designed for agitating applications
Features:
1. Compact structure, modular design
2. Single-stage, two-stage and three-stage sizes
3. High reduction ratio and torque density
4. Long service life
5. Can be combined with other types of gearboxes (Such as R Series, K Series, F Series, S Series, UDL Series)
1. Compact structure, modular design
2. Single-stage, two-stage and three-stage sizes
3. High reduction ratio and torque density
4. Long service life
5. Can be combined with other types of gearboxes (Such as R Series, K Series, F Series, S Series, UDL Series)
Gearbox Parameters
Models | Output Shaft Dia. | Input Shaft Dia. | Power(kW) | Ratio | Max. Torque(Nm) |
R/RF18 | 20mm | - | 0.18~0.75 | 3.83~74.84 | 85 |
R/RF28 | 25mm | 16mm | 0.18~3 | 3.37~135.09 | 130 |
R/RF38 | 25mm | 16mm | 0.18~3 | 3.41~134.82 | 200 |
R/RF48 | 30mm | 19mm | 0.18~5.5 | 3.83~176.88 | 300 |
R/RF58 | 35mm | 19mm | 0.18~7.5 | 4.39~186.89 | 450 |
R/RF68 | 35mm | 19mm | 0.18~7.5 | 4.29~199.81 | 600 |
R/RF78 | 40mm | 24mm | 0.18~11 | 5.21~195.24 | 820 |
R/RF88 | 50mm | 28mm | 0.55~22 | 5.36~246.54 | 1550 |
R/RF98 | 60mm | 38mm | 0.55~30 | 4.49~289.6 | 3000 |
R/RF108 | 70mm | 42mm | 2.2~45 | 5.06~245.5 | 4300 |
R/RF138 | 90mm | 55mm | 5.5~55 | 5.51~223.34 | 8000 |
R/RF148 | 110mm | 55mm | 11~90 | 5.00~163.46 | 13000 |
R/RF168 | 120mm | 70mm | 11~160 | 8.77~196.41 | 18000 |
